RADWIN 2000 E 2.5Gbps Point-to-Point  (RW-2U60-E2MM)

Product overview

RADWIN 2000 E is a premium, ultra-capacity Point-to-Point (PtP) solution for backhaul, access and for

connecting a wide variety of bandwidth demanding applications.

RADWIN 2000 E Point-to-Point is an outdoor radio that works in the 5.925-7.125GHz band and delivers up to 2.5Gbps.

The radio ensures outstanding performance and the highest possible throughput in congested spectrum,

using a field-proven air interface. The unit comes with an integrated antenna that assures best interference

mitigation via remarkably low side lobe levels. RADWIN 2000 E exceptionally powerful packet-switching

performance facilitates high short packet traffic. It also leverages upon the industry-strong encryption scheme

(AES 256), to ensure top level security. RADWIN 2000 E enables radio collocation using a built-in GPS, to save

upon hub tower space when deployed in the hub site. IP67 compliant, RADWIN 2000 E is extremely durable.

Product Highlights

» Up to 2.5Gbps net aggregated1              » 5.925-7.125 GHz

» Ch. BW 20 / 40 / 80 / 160 MHz1              » Connecte

» Up to 4096QAM                                         » Latency (avg) < 2.5msec

» Up to 120 km / 75 miles                           » Adaptive modulation

» Dynamic CBW selection                            » Configurable UL/DL ratio

» TDD synchronization for colocation2     » AES256 over-the-air encryption

» 8 queues QOS (Diffserv/802.1P) 2           » Built-in GPS

» Highly durable - IP 67                                » GPS-based regulation identification
